Zimmermann 348mm Front RH Brake Disc 150.2937.20
Part No. 150.2937.20
Check this part fits your car
Select your vehicle and we will confirm it against the 41 variants listed for this part.
$362.00
incl. GST
Front axle
348 x 36 mm
Fits 41 vehicle variants
Returned items must be unused and in the original unopened packaging. Return postage is paid by the buyer.
Estimate delivery date and cost
Technical specification
Disc typeInternally vented
Iron gradeHigh-carbon cast iron
Surface finishCorrosion-protective coating
Outside diameter348 mm
Thickness when new36 mm
Height66 mm
Stud holes5
Stud circle (PCD)112 mm
Centre bore67 mm
ApprovalECE R90 approved
Minimum (discard) thickness34.4 mm
Part weight12.9 kg
Hole pattern6/5
OE & OEM cross-reference
Supplier part number
150.2937.20
Fits OE / OEM numbers
3411 6 860 912
3410 6 880 076
3411 6 860 912
43512-WAA02
Vehicle fitment
41 variants
| Make & model | Chassis | Variant | Years | Power |
|---|---|---|---|---|
| BMW 3 Series | G20, G80, G28 | 320 d | 2018–now | 140 kW |
| BMW 3 Series | G20, G80, G28 | 330 i | 2018–now | 190 kW |
| BMW 3 Series | G20, G80, G28 | 320 i | 2019–now | 135 kW |
| BMW 3 Series | G20, G80, G28 | 330 e Plug-in-Hybrid | 2019–now | 215 kW |
| BMW 3 Series | G20, G80, G28 | M 340 i xDrive | 2019–now | 275 kW |
| BMW 3 Series Touring | G21, G81 | 330 i | 2019–now | 190 kW |
| BMW 4 Series Convertible | G23, G83 | 420 i, 425 i | 2020–now | 135 kW |
| BMW 4 Series Convertible | G23, G83 | 430 i | 2020–now | 190 kW |
| BMW 4 Series Coupe | G22, G82 | 420 i, 425 i | 2020–now | 135 kW |
| BMW 4 Series Coupe | G22, G82 | 430 i | 2020–now | 190 kW |
Product overview
Zimmermann 150.2937.20 is an internally vented brake disc (rotor). The disc is 348 mm in diameter and 36 mm thick when new, with a 66 mm hat height. The minimum (discard) thickness is 34.4 mm. It has 5 stud holes on a 112 mm stud circle (PCD), with a 67 mm centre bore. The disc is coated for corrosion protection and made from high-carbon cast iron. It is ECE R90 approved, the European type-approval standard for replacement brake parts. Cross-referenced to BMW OE 3411 6 860 912 and 2 other OE numbers. Confirmed to fit 41 Australian-market variants; the full list is in the fitment table on this page.
