Zimmermann 280mm Brake Disc Set (2 pcs) 150.3425.20
Part No. 150.3425.20
Check this part fits your car
Select your vehicle and we will confirm it against the 3 variants listed for this part.
$260.00
incl. GST
Rear axle
280 x 10 mm
Fits 3 vehicle variants
Returned items must be unused and in the original unopened packaging. Return postage is paid by the buyer.
Estimate delivery date and cost
Technical specification
Disc typeSolid
Iron gradeHigh-carbon cast iron
Surface finishCorrosion-protective coating
Outside diameter280 mm
Thickness when new10 mm
Height66 mm
Stud holes5
Stud circle (PCD)120 mm
Centre bore75 mm
ApprovalECE R90 approved
Minimum (discard) thickness8.4 mm
Part weight4.42 kg
Hole pattern6/5
OE & OEM cross-reference
Supplier part number
150.3425.20
Fits OE / OEM numbers
3421 6 764 647
3421 6 855 001
Vehicle fitment
3 variants
| Make & model | Chassis | Variant | Years | Power |
|---|---|---|---|---|
| BMW 1 Series | E87 | 116 i | 2004–2011 | 85 kW |
| BMW 1 Series | E87 | 118 i | 2004–2007 | 95 kW |
| BMW 1 Series | E87 | 118 d | 2007–2011 | 105 kW |
Product overview
Zimmermann 150.3425.20 is a pair of solid brake discs (rotors). Each disc is 280 mm in diameter and 10 mm thick when new, with a 66 mm hat height. The minimum (discard) thickness is 8.4 mm. Each disc has 5 stud holes on a 120 mm stud circle (PCD), with a 75 mm centre bore. The discs are coated for corrosion protection and made from high-carbon cast iron. They are ECE R90 approved, the European type-approval standard for replacement brake parts. Cross-referenced to BMW OE 3421 6 764 647 and 1 other OE number. Confirmed to fit 3 Australian-market variants; the full list is in the fitment table on this page.
