Zimmermann 284mm Brake Disc Set (2 pcs) 150.3423.20
Part No. 150.3423.20
$324.00
incl. GST
12-month warranty
In stock — ships in 1–2 business days
Estimate delivery date
Technical specification
Brake Disc TypeInternally Vented
MachiningHigh-carbon
SurfaceCoated
Outer diameter [mm]284
Brake Disc Thickness [mm]22
Height [mm]73
Rim Hole Number5
Bolt Hole Circle Ø [mm]120
Centering Diameter [mm]79
Test MarkECE R90 APPROVED
Minimum thickness [mm]20.4
Weight [kg]6.34
Hole Arrangement / Number6/5
OE & OEM cross-reference
Supplier part number
150.3423.20
Fits OE / OEM numbers
3411 6 764 629
3411 6 854 996
Vehicle fitment
3 variants
| Make & model | Chassis | Variant | Years | Power |
|---|---|---|---|---|
| BMW 1 Series | E87 | 116 i | 2004–2011 | 85 kW |
| BMW 1 Series | E87 | 118 i | 2004–2007 | 95 kW |
| BMW 1 Series | E87 | 118 d | 2007–2011 | 105 kW |
Product overview
Upgrade your braking performance with the Zimmermann 284mm Brake Disc Set (150.3423.20) from 86. Designed for precision, this set features internally vented, high-carbon discs coated for durability, ensuring optimal heat dissipation and reduced fade. With an outer diameter of 284mm and a thickness of 22mm, these discs are engineered for a perfect fit across 14 vehicle applications, including OE replacements for BMW. ECE R90 approved, they provide enhanced safety and reliability. Weighing 6.34 kg, they are built to last. Elevate your vehicle's stopping power—order your Zimmermann Brake Disc Set today!
