Zimmermann 298mm Brake Disc Set (2 pcs) 150.1286.20

Name: Zimmermann 298mm Brake Disc Set (2 pcs) 150.1286.20
Brand: Zimmermann
SKU: ZIM-00022
Price: 280.00 AUD
Availability: InStock

Part No. 150.1286.20

Low stock 4 OE references

Check this part fits your car

Select your vehicle and we will confirm it against the 9 variants listed for this part.

$280.00 incl. GST

Rear axle 298 x 20 mm Fits 9 vehicle variants

Manufacturer's warranty Processed within 2 business days 30-day change-of-mind returns

Returned items must be unused and in the original unopened packaging. Return postage is paid by the buyer.

Estimate delivery date and cost

Technical specification

Disc typeExternally vented

Iron gradeHigh-carbon cast iron

Surface finishCorrosion-protective coating

Outside diameter298 mm

Thickness when new20 mm

Height61 mm

Stud holes5

Stud circle (PCD)120 mm

Centre bore75 mm

ApprovalECE R90 approved

Minimum (discard) thickness18.4 mm

Part weight6.97 kg

Hole pattern6/5

OE & OEM cross-reference

Supplier part number

150.1286.20

Fits OE / OEM numbers

3421 1 163 153 3421 1 164 175 3421 1 164 840 3421 6 767 060

Vehicle fitment

9 variants

Make & model	Chassis	Variant	Years	Power
BMW 5 Series	E39	528 i	1995–2000	142 kW
BMW 5 Series	E39	520 i	1996–2003	110 kW
BMW 5 Series	E39	540 i	1996–2003	210 kW
BMW 5 Series	E39	535 i	1996–1998	173 kW
BMW 5 Series	E39	535 i	1998–2003	180 kW
BMW 5 Series	E39	525 i	2000–2003	141 kW
BMW 5 Series	E39	530 i	2000–2003	170 kW
BMW 5 Series Touring	E39	528 i	1996–2000	142 kW
BMW 5 Series Touring	E39	530 i	2000–2003	170 kW
No vehicles match your search.

Product overview

Zimmermann 150.1286.20 is a pair of externally vented brake discs (rotors). Each disc is 298 mm in diameter and 20 mm thick when new, with a 61 mm hat height. The minimum (discard) thickness is 18.4 mm. Each disc has 5 stud holes on a 120 mm stud circle (PCD), with a 75 mm centre bore. The discs are coated for corrosion protection and made from high-carbon cast iron. They are ECE R90 approved, the European type-approval standard for replacement brake parts. Cross-referenced to BMW OE 3421 1 163 153 and 3 other OE numbers. Confirmed to fit 9 Australian-market variants; the full list is in the fitment table on this page.
