Zimmermann 312mm Brake Disc Set (2 pcs) 100.1240.20

Name: Zimmermann 312mm Brake Disc Set (2 pcs) 100.1240.20
Brand: Zimmermann
SKU: ZIM-00004
Price: 334.00 AUD
Availability: InStock

Part No. 100.1240.20

Low stock 5 OE references

Check this part fits your car

Select your vehicle and we will confirm it against the 21 variants listed for this part.

$334.00 incl. GST

Front axle 312 x 25 mm Fits 21 vehicle variants

Manufacturer's warranty Processed within 2 business days 30-day change-of-mind returns

Returned items must be unused and in the original unopened packaging. Return postage is paid by the buyer.

Estimate delivery date and cost

Technical specification

Disc typeInternally vented

Iron gradeHigh-carbon cast iron

Surface finishCorrosion-protective coating

Outside diameter312 mm

Thickness when new25 mm

Height34 mm

Stud holes5

Stud circle (PCD)100 mm

Centre bore65 mm

ApprovalECE R90 approved

Minimum (discard) thickness23 mm

Part weight7.9 kg

Hole pattern10/5

OE & OEM cross-reference

Supplier part number

100.1240.20

Fits OE / OEM numbers

8L0 615 301 8N0 615 301 A 8L0 615 301 A JZW 615 301 G 8N0 615 301 A

Vehicle fitment 21 variants

Make & model	Chassis	Variant	Years	Power
AUDI A3	8L1	1.8 T quattro	1998–2003	132 kW
AUDI A3	8L1	S3 quattro	1999–2002	154 kW
AUDI A3	8L1	S3 quattro	2001–2003	165 kW
AUDI TT	8N3	1.8 T	1998–2006	132 kW
AUDI TT	8N3	1.8 T quattro	1998–2006	165 kW
AUDI TT	8N3	1.8 T	2002–2006	110 kW
AUDI TT	8N3	1.8 T	2005–2006	120 kW
AUDI TT	8N3	1.8 T	2005–2006	140 kW
AUDI TT Roadster	8N9	1.8 T	1999–2006	132 kW
AUDI TT Roadster	8N9	1.8 T quattro	1999–2006	165 kW
AUDI TT Roadster	8N9	1.8 T	2005–2006	140 kW
VW Bora I	1J2	1.6	1998–2005	74 kW
VW Bora I	1J2	2.0	1998–2013	85 kW
VW Bora I	1J2	2.3 V5	1998–2000	110 kW
VW Bora I	1J2	2.8 V6 4motion	1999–2005	150 kW
VW Bora I	1J2	1.9 TDI	2000–2005	110 kW
VW Bora I	1J2	2.3 V5	2000–2005	125 kW
VW Golf IV	1J1	1.8 T	1997–2005	110 kW
VW Golf IV	1J1	2.8 VR6 4motion	1999–2005	150 kW
VW Golf IV	1J1	2.3 V5	2000–2005	125 kW
VW Polo	9N_, 9A_	1.8 GTI	2005–2009	110 kW
No vehicles match your search.

Product overview

Zimmermann 100.1240.20 is a pair of internally vented brake discs (rotors). Each disc is 312 mm in diameter and 25 mm thick when new, with a 34 mm hat height. The minimum (discard) thickness is 23 mm. Each disc has 5 stud holes on a 100 mm stud circle (PCD), with a 65 mm centre bore. The discs are coated for corrosion protection and made from high-carbon cast iron. They are ECE R90 approved, the European type-approval standard for replacement brake parts. Cross-referenced to VAG OE 8L0 615 301 and 3 other OE numbers. Confirmed to fit 21 Australian-market variants; the full list is in the fitment table on this page.
