Zimmermann 360mm Front RH Brake Disc 150.3458.70
Part No. 150.3458.70
Check this part fits your car
Select your vehicle and we will confirm it against the 4 variants listed for this part.
$847.00
incl. GST
Front axle
360 x 30 mm
Fits 4 vehicle variants
Returned items must be unused and in the original unopened packaging. Return postage is paid by the buyer.
Estimate delivery date and cost
Technical specification
Disc typeVented, Cross-drilled, Two-piece (alloy hat, iron ring)
ConstructionFloating alloy hat
Iron gradeAlloyed high-carbon cast iron
Surface finishCorrosion-protective coating
Outside diameter360 mm
Thickness when new30 mm
Height62 mm
Stud holes5
Stud circle (PCD)120 mm
Centre bore79 mm
ApprovalECE R90 approved
Minimum (discard) thickness28.4 mm
Part weight10.2 kg
Hole pattern10/5
OE & OEM cross-reference
Supplier part number
150.3458.70
Fits OE / OEM numbers
3411 2 283 386
3411 2 283 802
Vehicle fitment
4 variants
| Make & model | Chassis | Variant | Years | Power |
|---|---|---|---|---|
| BMW 1 Series Coupe | E82 | M | 2011–2012 | 250 kW |
| BMW 3 Series | E90 | M3 | 2007–2011 | 309 kW |
| BMW 3 Series Convertible | E93 | M3 | 2008–2013 | 309 kW |
| BMW 3 Series Coupe | E92 | M3 | 2007–2013 | 309 kW |
Product overview
Zimmermann 150.3458.70 is a vented, cross-drilled, two-piece brake disc (rotor). The disc is 360 mm in diameter and 30 mm thick when new, with a 62 mm hat height. The minimum (discard) thickness is 28.4 mm. It has 5 stud holes on a 120 mm stud circle (PCD), with a 79 mm centre bore. The disc is coated for corrosion protection, made from alloyed high-carbon cast iron, and built with a floating alloy hat. It is ECE R90 approved, the European type-approval standard for replacement brake parts. Cross-referenced to BMW OE 3411 2 283 386 and 1 other OE number. Confirmed to fit 4 Australian-market variants; the full list is in the fitment table on this page.
