Zimmermann 280mm Brake Disc Set (2 pcs) 150.2931.20
Part No. 150.2931.20
Check this part fits your car
Select your vehicle and we will confirm it against the 12 variants listed for this part.
$266.00
incl. GST
Rear axle
280 x 10 mm
Fits 12 vehicle variants
Returned items must be unused and in the original unopened packaging. Return postage is paid by the buyer.
Estimate delivery date and cost
Technical specification
Disc typeSolid
Iron gradeHigh-carbon cast iron
Surface finishCorrosion-protective coating
Outside diameter280 mm
Thickness when new10 mm
Height51 mm
Stud holes5
Stud circle (PCD)112 mm
Centre bore67 mm
ApprovalECE R90 approved
Minimum (discard) thickness8.4 mm
Part weight4 kg
Hole pattern6/5
OE & OEM cross-reference
Supplier part number
150.2931.20
Fits OE / OEM numbers
3421 6 799 367
3421 6 861 013
3421 6 861 013
Vehicle fitment
12 variants
| Make & model | Chassis | Variant | Years | Power |
|---|---|---|---|---|
| BMW 1 Series | F40 | 118 i | 2019–now | 103 kW |
| BMW 2 Series Active Tourer | F45 | 218 d | 2013–now | 110 kW |
| BMW 2 Series Active Tourer | F45 | 220 i | 2014–now | 141 kW |
| BMW 2 Series Active Tourer | F45 | 218 i | 2014–now | 100 kW |
| BMW X1 | F48 | sDrive 18 d | 2015–now | 110 kW |
| BMW X1 | F48 | sDrive 18 i | 2017–now | 103 kW |
| BMW X2 | F39 | sDrive 18 i, sDrive 20i | 2018–now | 103 kW |
| BMW i3 | I01 | Electric | 2013–now | 125 kW |
| BMW i3 | I01 | Electric, electric TOP | 2013–now | 75 kW |
| BMW i3 | I01 | Range Extender | 2013–now | 125 kW |
Product overview
Zimmermann 150.2931.20 is a pair of solid brake discs (rotors). Each disc is 280 mm in diameter and 10 mm thick when new, with a 51 mm hat height. The minimum (discard) thickness is 8.4 mm. Each disc has 5 stud holes on a 112 mm stud circle (PCD), with a 67 mm centre bore. The discs are coated for corrosion protection and made from high-carbon cast iron. They are ECE R90 approved, the European type-approval standard for replacement brake parts. Cross-referenced to BMW OE 3421 6 799 367 and 1 other OE number. Confirmed to fit 12 Australian-market variants; the full list is in the fitment table on this page.
