Zimmermann 300mm Brake Disc Set (2 pcs) 600.3254.20
Part No. 600.3254.20
Check this part fits your car
Select your vehicle and we will confirm it against the 8 variants listed for this part.
$388.00
incl. GST
Rear axle
300 x 22 mm
Fits 8 vehicle variants
Returned items must be unused and in the original unopened packaging. Return postage is paid by the buyer.
Estimate delivery date and cost
Technical specification
Disc typeExternally vented
Iron gradeHigh-carbon cast iron
Surface finishCorrosion-protective coating
Outside diameter300 mm
Thickness when new22 mm
Height51 mm
Stud holes5
Stud circle (PCD)120 mm
Centre bore76 mm
ApprovalECE R90 approved
Road approvalApproved for passenger cars and light commercials (M1/N1)
Minimum (discard) thickness19 mm
Part weight7.3 kg
Hole pattern6/5
OE & OEM cross-reference
Supplier part number
600.3254.20
Fits OE / OEM numbers
65508030001
2N0 615 601
Vehicle fitment
8 variants
| Make & model | Chassis | Variant | Years | Power |
|---|---|---|---|---|
| VW Amarok | 2HA, 2HB… | 3.0 TDI 4motion, 3.0 TDI Highline V6 4motion | 2016–now | 165 kW |
| VW Amarok | 2HA, 2HB… | 3.0 TDI 4motion | 2018–now | 190 kW |
| VW Crafter Bus | SYI, SYJ | 2.0 TDI | 2016–now | 130 kW |
| VW Crafter Platform/Chassis | SZ_ | 2.0 TDI | 2016–now | 103 kW |
| VW Crafter Platform/Chassis | SZ_ | 2.0 TDI | 2016–now | 130 kW |
| VW Crafter Van | SY_, SX_ | 2.0 TDI | 2016–now | 103 kW |
| VW Crafter Van | SY_, SX_ | 2.0 TDI | 2016–now | 130 kW |
| VW Crafter Van | SY_, SX_ | 2.0 TDI 4motion | 2017–now | 130 kW |
Product overview
Zimmermann 600.3254.20 is a pair of externally vented brake discs (rotors). Each disc is 300 mm in diameter and 22 mm thick when new, with a 51 mm hat height. The minimum (discard) thickness is 19 mm. Each disc has 5 stud holes on a 120 mm stud circle (PCD), with a 76 mm centre bore. The discs are coated for corrosion protection and made from high-carbon cast iron. They are ECE R90 approved, the European type-approval standard for replacement brake parts. Cross-referenced to VAG OE 2N0 615 601 and 1 other OE number. Confirmed to fit 8 Australian-market variants; the full list is in the fitment table on this page.
