Zimmermann 332mm Brake Disc Set (2 pcs) 600.3256.20
Part No. 600.3256.20
Check this part fits your car
Select your vehicle and we will confirm it against the 2 variants listed for this part.
$504.00
incl. GST
Front axle
332 x 30 mm
Fits 2 vehicle variants
Returned items must be unused and in the original unopened packaging. Return postage is paid by the buyer.
Estimate delivery date and cost
Technical specification
Disc typeInternally vented
Iron gradeHigh-carbon cast iron
Surface finishCorrosion-protective coating
Outside diameter332 mm
Thickness when new30 mm
Height57 mm
Stud holes5
Stud circle (PCD)120 mm
Centre bore76 mm
ApprovalECE R90 approved
Minimum (discard) thickness27 mm
Part weight11.2 kg
Hole pattern6/5
OE & OEM cross-reference
Supplier part number
600.3256.20
Fits OE / OEM numbers
2H6 615 301
Vehicle fitment
2 variants
| Make & model | Chassis | Variant | Years | Power |
|---|---|---|---|---|
| VW Amarok | 2HA, 2HB… | 3.0 TDI 4motion, 3.0 TDI Highline V6 4motion | 2016–now | 165 kW |
| VW Amarok | 2HA, 2HB… | 3.0 TDI 4motion | 2018–now | 190 kW |
Product overview
Zimmermann 600.3256.20 is a pair of internally vented brake discs (rotors). Each disc is 332 mm in diameter and 30 mm thick when new, with a 57 mm hat height. The minimum (discard) thickness is 27 mm. Each disc has 5 stud holes on a 120 mm stud circle (PCD), with a 76 mm centre bore. The discs are coated for corrosion protection and made from high-carbon cast iron. They are ECE R90 approved, the European type-approval standard for replacement brake parts. Cross-referenced to VAG OE 2H6 615 301. Confirmed to fit 2 Australian-market variants; the full list is in the fitment table on this page.
