Zimmermann 330mm Brake Disc Set (2 pcs) 100.3358.20

Name: Zimmermann 330mm Brake Disc Set (2 pcs) 100.3358.20
Brand: Zimmermann
SKU: ZIM-00010
Price: 378.00 AUD
Availability: InStock

Part No. 100.3358.20

Low stock 19 OE references

Check this part fits your car

Select your vehicle and we will confirm it against the 186 variants listed for this part.

$378.00 incl. GST

Rear axle 330 x 22 mm Fits 186 vehicle variants

Manufacturer's warranty Processed within 2 business days 30-day change-of-mind returns

Returned items must be unused and in the original unopened packaging. Return postage is paid by the buyer.

Estimate delivery date and cost

Technical specification

Disc typeInternally vented

Iron gradeHigh-carbon cast iron

Surface finishCorrosion-protective coating

Outside diameter330 mm

Thickness when new22 mm

Height36 mm

Stud holes5

Stud circle (PCD)112 mm

Centre bore68 mm

ApprovalECE R90 approved

Minimum (discard) thickness20 mm

Part weight7.5 kg

Hole pattern6/5

OE & OEM cross-reference

Supplier part number

100.3358.20

Fits OE / OEM numbers

4H0 615 601 K 4H0 615 601 H 4H0 615 601 Q 8W0 615 601 E 8W0 615 601 K L80D615601 95B 615 601 A 95B 615 601 G 95B615601A 95B615601G 80A 615 601 C 4H0 615 601 H 4H0 615 601 K 4H0 615 601 Q 4H0 615 601 D 8W0 615 601 E 8W0 615 601 K 4H0 615 601 Q 4H0 615 601 K

Vehicle fitment

186 variants

Make & model	Chassis	Variant	Years	Power
Audi A4 B8	8K2	1.8 TFSI	2007–2012	118 kW
Audi A4 B8	8K2	2.0 TDI	2007–2015	105 kW
Audi A4 B8	8K2	2.0 TDI	2007–2015	100 kW
Audi A4 B8	8K2	2.7 TDI	2007–2012	140 kW
Audi A4 B8	8K2	3.0 TDI quattro	2007–2012	176 kW
Audi A4 B8	8K2	3.2 FSI quattro	2007–2012	195 kW
Audi A4 B8	8K2	2.0 TDI	2008–2012	125 kW
Audi A4 B8	8K2	2.0 TFSI	2008–2015	132 kW
Audi A4 B8	8K2	2.0 TFSI quattro	2008–2015	155 kW
Audi A4 B8	8K2	S4 quattro	2008–2015	245 kW
Audi A4 B8	8K2	1.8 TFSI	2011–2015	125 kW
Audi A4 B8	8K2	2.0 TDI	2011–2015	130 kW
Audi A4 B8	8K2	2.0 TDI quattro	2011–2015	130 kW
Audi A4 B8	8K2	3.0 TDI	2011–2015	150 kW
Audi A4 B8	8K2	3.0 TDI quattro	2011–2015	180 kW
Audi A4 B8	8K2	3.0 TFSI quattro	2012–2015	200 kW
Audi A4 B8	8K2	2.0 TFSI	2013–2015	165 kW
Audi A4 B8	8K2	2.0 TFSI quattro	2013–2015	165 kW
Audi A4 Allroad B8	8KH	2.0 TDI quattro	2011–2016	130 kW
Audi A4 Allroad B8	8KH	2.0 TDI quattro	2013–2016	140 kW
Audi A4 Allroad B9	8WH, 8WJ	2.0 TDI quattro	2016–now	140 kW
Audi A4 Allroad B9	8WH, 8WJ	2.0 TFSI quattro	2016–now	185 kW
Audi A4 B8 Avant	8K5	1.8 TFSI	2007–2012	118 kW
Audi A4 B8 Avant	8K5	2.0 TDI	2008–2015	105 kW
Audi A4 B8 Avant	8K5	2.0 TDI	2008–2015	100 kW
Audi A4 B8 Avant	8K5	2.7 TDI	2008–2012	140 kW
Audi A4 B8 Avant	8K5	3.0 TDI quattro	2008–2012	176 kW
Audi A4 B8 Avant	8K5	2.0 TFSI	2008–2013	155 kW
Audi A4 B8 Avant	8K5	2.0 TFSI	2008–2015	132 kW
Audi A4 B8 Avant	8K5	2.0 TFSI quattro	2008–2015	155 kW
Audi A4 B8 Avant	8K5	S4 quattro	2008–2015	245 kW
Audi A4 B8 Avant	8K5	1.8 TFSI, 1.8 TFSI Ambiente	2011–2015	125 kW
Audi A4 B8 Avant	8K5	2.0 TDI	2011–2015	130 kW
Audi A4 B8 Avant	8K5	3.0 TDI	2011–2015	150 kW
Audi A4 B8 Avant	8K5	2.0 TFSI	2013–2015	165 kW
Audi A4 B8 Avant	8K5	2.0 TFSI quattro	2013–2015	165 kW
Audi A4 B9	8W2, 8WC	2.0 TFSI quattro	2015–now	185 kW
Audi A4 B9	8W2, 8WC	2.0 TFSI, 2.0 TFSI Ambiente Attraction Launch Edition	2015–now	140 kW
Audi A4 B9	8W2, 8WC	1.4 TFSI	2015–2019	110 kW
Audi A4 B9	8W2, 8WC	2.0 TDI quattro	2015–2019	140 kW
Audi A4 B9	8W2, 8WC	S4 quattro	2016–now	260 kW
Audi A4 B9	8W2, 8WC	35 TFSI Mild Hybrid	2018–now	110 kW
Audi A4 B9 Avant	8W5, 8WD	2.0 TFSI quattro	2015–2019	185 kW
Audi A4 B9 Avant	8W5, 8WD	2.0 TFSI, 2.0 TFSI Ambiente	2015–now	140 kW
Audi A4 B9 Avant	8W5, 8WD	S4 quattro	2016–2019	260 kW
Audi A5	8T3	3.0 TDI quattro	2007–2012	176 kW
Audi A5	8T3	3.2 FSI	2007–2012	195 kW
Audi A5	8T3	3.2 FSI quattro	2007–2012	195 kW
Audi A5	8T3	S5 quattro	2007–2012	260 kW
Audi A5	8T3	1.8 TFSI	2007–2017	125 kW
Audi A5	8T3	2.0 TFSI	2008–2013	155 kW
Audi A5	8T3	2.0 TFSI quattro	2008–2017	155 kW
Audi A5	8T3	2.0 TFSI	2008–2012	132 kW
Audi A5	8T3	2.0 TDI	2011–2017	130 kW
Audi A5	8T3	3.0 TDI quattro	2011–2017	180 kW
Audi A5	8T3	S5 quattro	2011–2017	245 kW
Audi A5	8T3	2.0 TDI quattro	2011–2017	130 kW
Audi A5	8T3	3.0 TFSI quattro	2011–2017	200 kW
Audi A5	8T3	2.0 45 TFSI quattro, 2.0 TFSI quattro	2013–2016	165 kW
Audi A5	8T3	1.8 35 TFSI, 1.8 TFSI	2015–2017	130 kW
Audi A5	8T3	2.0 45 TFSI quattro, 2.0 TFSI quattro	2015–2017	169 kW
Audi A5	F53, F5P	2.0 45 TFSI quattro, 2.0 TFSI quattro	2016–now	185 kW
Audi A5	F53, F5P	S5 quattro	2016–now	260 kW
Audi A5	F53, F5P	2.0 40 TFSI, 2.0 TFSI	2016–now	140 kW
Audi A5	F53, F5P	2.0 TDI quattro	2016–now	140 kW
Audi A5 Convertible	8F7	2.0 TFSI	2009–2012	132 kW
Audi A5 Convertible	8F7	2.0 TFSI	2009–2014	155 kW
Audi A5 Convertible	8F7	2.0 TFSI quattro	2009–2017	155 kW
Audi A5 Convertible	8F7	3.0 TDI quattro	2009–2012	176 kW
Audi A5 Convertible	8F7	3.2 FSI	2009–2012	195 kW
Audi A5 Convertible	8F7	3.2 FSI quattro	2009–2012	195 kW
Audi A5 Convertible	8F7	S5 quattro	2009–2017	245 kW
Audi A5 Convertible	8F7	1.8 TFSI	2009–2012	118 kW
Audi A5 Convertible	8F7	1.8 TFSI	2011–2016	125 kW
Audi A5 Convertible	8F7	2.0 TDI	2011–2017	130 kW
Audi A5 Convertible	8F7	3.0 TDI quattro	2011–2017	180 kW
Audi A5 Convertible	8F7	3.0 TFSI quattro	2011–2017	200 kW
Audi A5 Convertible	8F7	2.0 TDI quattro	2012–2015	130 kW
Audi A5 Convertible	8F7	2.0 45 TFSI quattro, 2.0 TFSI quattro	2013–2016	165 kW
Audi A5 Convertible	8F7	1.8 TFSI	2015–2017	130 kW
Audi A5 Convertible	8F7	2.0 45 TFSI quattro, 2.0 TFSI quattro	2015–2017	169 kW
Audi A5 Sportback	8TA	2.0 TFSI	2009–2013	155 kW
Audi A5 Sportback	8TA	2.0 TFSI	2009–2014	132 kW
Audi A5 Sportback	8TA	2.0 TFSI quattro	2009–2017	155 kW
Audi A5 Sportback	8TA	3.0 TDI quattro	2009–2012	176 kW
Audi A5 Sportback	8TA	3.0 TFSI quattro, S5 quattro	2010–2017	245 kW
Audi A5 Sportback	8TA	1.8 TFSI	2011–2017	125 kW
Audi A5 Sportback	8TA	2.0 TDI	2011–2017	130 kW
Audi A5 Sportback	8TA	3.0 TDI quattro	2011–2017	180 kW
Audi A5 Sportback	8TA	2.0 TDI quattro	2011–2017	130 kW
Audi A5 Sportback	8TA	3.0 TFSI quattro	2011–2017	200 kW
Audi A5 Sportback	8TA	2.0 45 TFSI quattro, 2.0 TFSI Ambition S-Tronic quattro, 2.0 TFSI quattro	2013–2016	165 kW
Audi A5 Sportback	8TA	1.8 35 TFSI, 1.8 TFSI	2015–2017	130 kW
Audi A5 Sportback	8TA	2.0 45 TFSI quattro, 2.0 TFSI quattro	2015–2017	169 kW
Audi A5 Convertible	F57, F5E	2.0 45 TFSI quattro, 2.0 TFSI quattro	2016–now	185 kW
Audi A5 Convertible	F57, F5E	2.0 40 TFSI, 2.0 TFSI	2017–2019	140 kW
Audi A5 Convertible	F57, F5E	S5 quattro	2017–now	260 kW
Audi A5 Sportback	F5A, F5F	2.0 45 TFSI quattro, 2.0 TFSI quattro	2016–now	185 kW
Audi A5 Sportback	F5A, F5F	S5 quattro	2016–now	260 kW
Audi A5 Sportback	F5A, F5F	2.0 TDI quattro	2016–now	140 kW
Audi A5 Sportback	F5A, F5F	2.0 40 TFSI, 2.0 TFSI	2017–now	140 kW
Audi A6 C7	4G2, 4GC	2.8 FSI quattro	2010–2015	150 kW
Audi A6 C7	4G2, 4GC	3.0 TFSI quattro	2010–2012	220 kW
Audi A6 C7	4G2, 4GC	2.0 TDI	2011–2018	130 kW
Audi A6 C7	4G2, 4GC	3.0 TDI quattro	2011–2018	150 kW
Audi A6 C7	4G2, 4GC	3.0 TDI quattro	2011–2018	180 kW
Audi A6 C7	4G2, 4GC	3.0 TFSI quattro	2011–2018	228 kW
Audi A6 C7	4G2, 4GC	2.0 TFSI	2011–2018	132 kW
Audi A6 C7	4G2, 4GC	3.0 TDI quattro	2011–2018	230 kW
Audi A6 C7	4G2, 4GC	S6 quattro	2012–2018	309 kW
Audi A6 C7	4G2, 4GC	2.0 35 TDI Matrix, 2.0 TDI	2013–2018	140 kW
Audi A6 C7	4G2, 4GC	2.0 TFSI quattro	2014–2018	185 kW
Audi A6 C7	4G2, 4GC	1.8 35 TFSI Matrix, 1.8 TFSI	2014–2018	140 kW
Audi A6 C7	4G2, 4GC	3.0 TDI	2014–2018	160 kW
Audi A6 C7	4G2, 4GC	3.0 TDI quattro	2014–2018	160 kW
Audi A6 C7	4G2, 4GC	3.0 TDI quattro	2014–2018	235 kW
Audi A6 C7	4G2, 4GC	S6 quattro	2014–2018	331 kW
Audi A6 Allroad C7	4GH, 4GJ	3.0 TDI quattro	2012–2016	180 kW
Audi A6 Allroad C7	4GH, 4GJ	3.0 TDI quattro	2014–2018	160 kW
Audi A6 C7 Avant	4G5, 4GD	2.0 TDI	2011–2018	130 kW
Audi A6 C7 Avant	4G5, 4GD	2.0 TFSI	2011–2018	132 kW
Audi A6 C7 Avant	4G5, 4GD	3.0 TDI quattro	2014–2018	160 kW
Audi A6 C8	4A2	55 TFSi Mild Hybrid quattro	2018–now	250 kW
Audi A6 C8	4A2	45 TFSI Mild Hybrid quattro	2018–now	180 kW
Audi A7 Sportback	4GA, 4GF	3.0 TDI quattro	2010–2016	180 kW
Audi A7 Sportback	4GA, 4GF	3.0 TFSI quattro	2010–2012	220 kW
Audi A7 Sportback	4GA, 4GF	3.0 TFSI quattro	2011–2015	228 kW
Audi A7 Sportback	4GA, 4GF	3.0 TDI quattro	2011–2015	230 kW
Audi A7 Sportback	4GA, 4GF	S7 quattro	2012–2015	309 kW
Audi A7 Sportback	4GA, 4GF	3.0 TDI quattro	2014–2018	235 kW
Audi A7 Sportback	4GA, 4GF	3.0 TDI quattro	2014–2018	160 kW
Audi A7 Sportback	4GA, 4GF	S7 quattro	2014–2018	331 kW
Audi A7 Sportback	4GA, 4GF	2.0 40 TFSI quattro, 2.0 TFSI quattro	2015–2018	185 kW
Audi A7 Sportback	4KA	55 TFSI Mild Hybrid quattro	2017–now	250 kW
Audi A7 Sportback	4KA	45 TFSI Mild hybrid quattro	2018–now	180 kW
Audi A8 D4	4H2, 4H8, 4HC, 4HL	4.2 FSI quattro	2009–2012	273 kW
Audi A8 D4	4H2, 4H8, 4HC, 4HL	4.2 TDI quattro	2009–2014	258 kW
Audi A8 D4	4H2, 4H8, 4HC, 4HL	3.0 TDI / 50 TDI quattro, 3.0 TDI quattro	2010–2018	184 kW
Audi A8 D4	4H2, 4H8, 4HC, 4HL	S8 quattro	2012–2018	382 kW
Audi A8 D4	4H2, 4H8, 4HC, 4HL	3.0 TDI quattro	2013–2018	190 kW
Audi A8 D4	4H2, 4H8, 4HC, 4HL	4.2 TDI quattro	2013–2018	283 kW
Audi A8 D4	4H2, 4H8, 4HC, 4HL	3.0 TDI quattro	2015–2018	193 kW
Audi A8 D5	4N2, 4N8, 4NC, 4NL	50 TDI Mild Hybrid quattro	2017–now	210 kW
Audi A8 D5	4N2, 4N8, 4NC, 4NL	55 TFSI Mild Hybrid quattro	2017–now	250 kW
Audi Q5	8RB	2.0 TDI quattro	2008–2012	125 kW
Audi Q5	8RB	2.0 TFSI quattro	2008–2012	155 kW
Audi Q5	8RB	3.0 TDI quattro	2008–2017	176 kW
Audi Q5	8RB	3.2 FSI quattro	2008–2012	199 kW
Audi Q5	8RB	2.0 TDI quattro	2012–2017	130 kW
Audi Q5	8RB	2.0 TFSI quattro	2012–2016	165 kW
Audi Q5	8RB	3.0 TDI quattro	2012–2017	180 kW
Audi Q5	8RB	3.0 TFSI quattro	2012–2017	200 kW
Audi Q5	8RB	SQ5 TDI quattro	2012–2015	230 kW
Audi Q5	8RB	2.0 TDI quattro	2013–2017	140 kW
Audi Q5	8RB	3.0 TDI quattro	2013–2017	190 kW
Audi Q5	8RB	SQ5 TDI quattro	2015–2017	240 kW
Audi Q5	8RB	2.0 TFSI quattro	2015–2017	169 kW
Audi Q5	8RB	SQ5 TDI quattro	2015–2017	250 kW
Audi Q5	FYB, FYG	2.0 TDI quattro	2016–2018	140 kW
Audi Q5	FYB, FYG	2.0 TFSI quattro	2016–now	185 kW
Audi Q5	FYB, FYG	SQ5 TFSI quattro	2016–now	260 kW
Audi Q5	FYB, FYG	3.0 TDI quattro	2017–2020	210 kW
Audi Q5	FYB, FYG	40 TDI quattro	2018–now	140 kW
Audi Q5	FYB, FYG	45 TFSI Mild Hybrid quattro	2018–now	180 kW
Audi Q5	FYB, FYG	SQ5 TDI Mild Hybrid quattro	2019–now	255 kW
Audi Q5	FYB, FYG	50 TDI quattro	2019–2020	210 kW
Audi Q5	FYB, FYG	SQ5 TDI Mild Hybrid	2021–now	251 kW
Audi Q7	4MB, 4MG	3.0 TDI quattro	2015–2019	200 kW
Audi Q7	4MB, 4MG	3.0 TDI quattro	2015–2019	160 kW
Audi Q7	4MB, 4MG	3.0 TDI e-tron quattro	2015–2019	275 kW
Audi Q7	4MB, 4MG	SQ7 TDI quattro	2016–2019	320 kW
Audi Q7	4MB, 4MG	45 TDI Mild Hybrid quattro	2018–now	170 kW
Audi Q7	4MB, 4MG	50 TDI Mild Hybrid quattro	2018–now	210 kW
Audi Q7	4MB, 4MG	55 TFSI Mild Hybrid quattro	2019–now	250 kW
Porsche Macan	95B	3.0 S	2014–2018	250 kW
Porsche Macan	95B	3.0 S Diesel	2014–2018	190 kW
Porsche Macan	95B	3.6 Turbo	2014–2018	294 kW
Porsche Macan	95B	2.0, 2.0 R4	2015–now	185 kW
Porsche Macan	95B	3.0 GTS	2015–2018	265 kW
Porsche Macan	95B	3.6 Turbo	2016–now	324 kW
Porsche Macan	95B	2.0 (95BAU1)	2018–now	195 kW
Porsche Macan	95B	2.9 Turbo AWD	2018–now	324 kW
Porsche Macan	95B	3.0 S	2018–now	260 kW
Porsche Macan	95B	GTS (95BBL1)	2019–now	280 kW
VW Touareg	CR7	3.0 TDI 4motion	2017–now	210 kW
VW Touareg	CR7	3.0 TDI 4motion	2018–now	170 kW
No vehicles match your search.

Product overview

Zimmermann 100.3358.20 is a pair of internally vented brake discs (rotors). Each disc is 330 mm in diameter and 22 mm thick when new, with a 36 mm hat height. The minimum (discard) thickness is 20 mm. Each disc has 5 stud holes on a 112 mm stud circle (PCD), with a 68 mm centre bore. The discs are coated for corrosion protection and made from high-carbon cast iron. They are ECE R90 approved, the European type-approval standard for replacement brake parts. Cross-referenced to Audi OE 4H0 615 601 K and 9 other OE numbers. Confirmed to fit 186 Australian-market variants; the full list is in the fitment table on this page.
