Zimmermann 360mm Front RH Brake Disc 600.3248.20
Part No. 600.3248.20
Check this part fits your car
Select your vehicle and we will confirm it against the 18 variants listed for this part.
$366.00
incl. GST
Front axle
360 x 36 mm
Fits 18 vehicle variants
Returned items must be unused and in the original unopened packaging. Return postage is paid by the buyer.
Estimate delivery date and cost
Technical specification
Disc typeInternally vented
Iron gradeHigh-carbon cast iron
Surface finishCorrosion-protective coating
Outside diameter360 mm
Thickness when new36 mm
Height68 mm
Stud holes5
Stud circle (PCD)130 mm
Centre bore85 mm
ApprovalECE R90 approved
Minimum (discard) thickness34 mm
Part weight13.5 kg
Hole pattern6/5
OE & OEM cross-reference
Supplier part number
600.3248.20
Fits OE / OEM numbers
958 351 404 01
958 351 404 00
7P6 615 302
7P6 615 302 A
7P6 615 302 B
Vehicle fitment
18 variants
| Make & model | Chassis | Variant | Years | Power |
|---|---|---|---|---|
| PORSCHE Cayenne | 92A | 3.0 Diesel | 2010–now | 176 kW |
| PORSCHE Cayenne | 92A | 3.6, 3.6 V6 | 2010–now | 220 kW |
| PORSCHE Cayenne | 92A | 4.8 S | 2010–now | 294 kW |
| PORSCHE Cayenne | 92A | 3.0 S E-Hybrid, 3.0 S E-Hybrid Platinium Edition, 3.0 S Hybrid | 2011–2017 | 306 kW |
| PORSCHE Cayenne | 92A | 3.0 Diesel | 2011–now | 180 kW |
| PORSCHE Cayenne | 92A | 4.8 GTS | 2012–now | 309 kW |
| PORSCHE Cayenne | 92A | 4.2 S Diesel | 2012–now | 281 kW |
| PORSCHE Cayenne | 92A | 3.0 Diesel | 2014–now | 193 kW |
| PORSCHE Cayenne | 92A | 3.6 S | 2014–now | 309 kW |
| PORSCHE Cayenne | 92A | 4.2 S Diesel | 2014–now | 283 kW |
Product overview
Zimmermann 600.3248.20 is an internally vented brake disc (rotor). The disc is 360 mm in diameter and 36 mm thick when new, with a 68 mm hat height. The minimum (discard) thickness is 34 mm. It has 5 stud holes on a 130 mm stud circle (PCD), with a 85 mm centre bore. The disc is coated for corrosion protection and made from high-carbon cast iron. It is ECE R90 approved, the European type-approval standard for replacement brake parts. Cross-referenced to Porsche OE 958 351 404 01 and 4 other OE numbers. Confirmed to fit 18 Australian-market variants; the full list is in the fitment table on this page.
