Zimmermann 330mm Brake Disc Set (2 pcs) 150.3428.20
Part No. 150.3428.20
Check this part fits your car
Select your vehicle and we will confirm it against the 28 variants listed for this part.
$398.00
incl. GST
Front axle
330 x 24 mm
Fits 28 vehicle variants
Returned items must be unused and in the original unopened packaging. Return postage is paid by the buyer.
Estimate delivery date and cost
Technical specification
Disc typeInternally vented
Iron gradeHigh-carbon cast iron
Surface finishCorrosion-protective coating
Outside diameter330 mm
Thickness when new24 mm
Height73 mm
Stud holes5
Stud circle (PCD)120 mm
Centre bore79 mm
ApprovalECE R90 approved
Minimum (discard) thickness22.4 mm
Part weight9.08 kg
Hole pattern6/5
OE & OEM cross-reference
Supplier part number
150.3428.20
Fits OE / OEM numbers
3411 6 854 999
3411 6 764 645
3411 6 854 999
3411 6 764 645
Vehicle fitment
28 variants
| Make & model | Chassis | Variant | Years | Power |
|---|---|---|---|---|
| BMW 1 Series | E87 | 130 i | 2005–2007 | 195 kW |
| BMW 1 Series | E87 | 123 d | 2007–2011 | 150 kW |
| BMW 1 Series Convertible | E88 | 123 d | 2008–2013 | 150 kW |
| BMW 1 Series Coupe | E82 | 123 d | 2007–2013 | 150 kW |
| BMW 3 Series | E90 | 320 d | 2004–2007 | 110 kW |
| BMW 3 Series | E90 | 320 d | 2004–2011 | 120 kW |
| BMW 3 Series | E90 | 325 i | 2004–2011 | 160 kW |
| BMW 3 Series | E90 | 330 i, 330 i M Sport | 2004–2011 | 190 kW |
| BMW 3 Series | E90 | 320 d | 2007–2009 | 125 kW |
| BMW 3 Series | E90 | 325 i, 328 i | 2007–2011 | 160 kW |
Product overview
Zimmermann 150.3428.20 is a pair of internally vented brake discs (rotors). Each disc is 330 mm in diameter and 24 mm thick when new, with a 73 mm hat height. The minimum (discard) thickness is 22.4 mm. Each disc has 5 stud holes on a 120 mm stud circle (PCD), with a 79 mm centre bore. The discs are coated for corrosion protection and made from high-carbon cast iron. They are ECE R90 approved, the European type-approval standard for replacement brake parts. Cross-referenced to BMW OE 3411 6 854 999 and 1 other OE number. Confirmed to fit 28 Australian-market variants; the full list is in the fitment table on this page.
