Zimmermann 336mm Brake Disc Set (2 pcs) 150.3430.20
Part No. 150.3430.20
Check this part fits your car
Select your vehicle and we will confirm it against the 24 variants listed for this part.
$394.00
incl. GST
Rear axle
336 x 22 mm
Fits 24 vehicle variants
Returned items must be unused and in the original unopened packaging. Return postage is paid by the buyer.
Estimate delivery date and cost
Technical specification
Disc typeInternally vented
Iron gradeHigh-carbon cast iron
Surface finishCorrosion-protective coating
Outside diameter336 mm
Thickness when new22 mm
Height67 mm
Stud holes5
Stud circle (PCD)120 mm
Centre bore75 mm
ApprovalECE R90 approved
Minimum (discard) thickness20.4 mm
Part weight8.2 kg
Hole pattern6/5
OE & OEM cross-reference
Supplier part number
150.3430.20
Fits OE / OEM numbers
3421 6 764 655
3421 6 855 004
3421 6 855 004
3421 6 764 655
Vehicle fitment
24 variants
| Make & model | Chassis | Variant | Years | Power |
|---|---|---|---|---|
| BMW 3 Series | E90 | 320 d | 2004–2007 | 110 kW |
| BMW 3 Series | E90 | 320 d | 2004–2011 | 120 kW |
| BMW 3 Series | E90 | 325 i | 2004–2011 | 160 kW |
| BMW 3 Series | E90 | 330 i, 330 i M Sport | 2004–2011 | 190 kW |
| BMW 3 Series | E90 | 335 i, 335 i M Sport | 2006–2011 | 225 kW |
| BMW 3 Series | E90 | 325 i, 328 i | 2007–2011 | 160 kW |
| BMW 3 Series | E90 | 320 d | 2007–2010 | 130 kW |
| BMW 3 Series | E90 | 330 i | 2007–2011 | 200 kW |
| BMW 3 Series | E90 | 330 d | 2008–2011 | 180 kW |
| BMW 3 Series | E90 | 320 d | 2010–2011 | 135 kW |
Product overview
Zimmermann 150.3430.20 is a pair of internally vented brake discs (rotors). Each disc is 336 mm in diameter and 22 mm thick when new, with a 67 mm hat height. The minimum (discard) thickness is 20.4 mm. Each disc has 5 stud holes on a 120 mm stud circle (PCD), with a 75 mm centre bore. The discs are coated for corrosion protection and made from high-carbon cast iron. They are ECE R90 approved, the European type-approval standard for replacement brake parts. Cross-referenced to BMW OE 3421 6 764 655 and 1 other OE number. Confirmed to fit 24 Australian-market variants; the full list is in the fitment table on this page.
