Zimmermann 312mm Brake Disc Set (2 pcs) 150.2900.20
Part No. 150.2900.20
Check this part fits your car
Select your vehicle and we will confirm it against the 82 variants listed for this part.
$382.00
incl. GST
Front axle
312 x 24 mm
Fits 82 vehicle variants
Returned items must be unused and in the original unopened packaging. Return postage is paid by the buyer.
Estimate delivery date and cost
Technical specification
Disc typeInternally vented
Iron gradeHigh-carbon cast iron
Surface finishCorrosion-protective coating
Outside diameter312 mm
Thickness when new24 mm
Height73 mm
Stud holes5
Stud circle (PCD)120 mm
Centre bore79 mm
Wheel bolt bore16.5 mm
ApprovalECE R90 approved
Minimum (discard) thickness22.4 mm
Part weight8.8 kg
Hole pattern6/5
OE & OEM cross-reference
Supplier part number
150.2900.20
Fits OE / OEM numbers
3411 8 848 417
3411 6 792 219
3411 6 792 219
Vehicle fitment
82 variants
| Make & model | Chassis | Variant | Years | Power |
|---|---|---|---|---|
| BMW 1 Series | F20 | 118 d | 2011–2015 | 105 kW |
| BMW 1 Series | F20 | 118 i, 120 i | 2011–2015 | 125 kW |
| BMW 1 Series | F20 | 125 i | 2012–2017 | 160 kW |
| BMW 1 Series | F20 | 118 d | 2015–2019 | 110 kW |
| BMW 1 Series | F20 | 118 i | 2015–2015 | 100 kW |
| BMW 1 Series | F20 | 120 i | 2015–2016 | 130 kW |
| BMW 1 Series | F20 | 118 i | 2015–2019 | 100 kW |
| BMW 1 Series | F20 | 120 i | 2016–2019 | 135 kW |
| BMW 1 Series | F20 | 125 i | 2016–2019 | 165 kW |
| BMW 2 Series Convertible | F23 | 220 i | 2014–2016 | 135 kW |
Product overview
Zimmermann 150.2900.20 is a pair of internally vented brake discs (rotors). Each disc is 312 mm in diameter and 24 mm thick when new, with a 73 mm hat height. The minimum (discard) thickness is 22.4 mm. Each disc has 5 stud holes on a 120 mm stud circle (PCD), with a 79 mm centre bore. The discs are coated for corrosion protection and made from high-carbon cast iron. They are ECE R90 approved, the European type-approval standard for replacement brake parts. Cross-referenced to BMW OE 3411 8 848 417 and 1 other OE number. Confirmed to fit 82 Australian-market variants; the full list is in the fitment table on this page.
