Zimmermann Brake Drum Set (2 pcs) 600.1967.20
Part No. 600.1967.20
Check this part fits your car
Select your vehicle and we will confirm it against the 10 variants listed for this part.
$516.00
incl. GST
Fits 10 vehicle variants
Returned items must be unused and in the original unopened packaging. Return postage is paid by the buyer.
Estimate delivery date and cost
Technical specification
Surface finishCorrosion-protective coating
Drum outside diameter335 mm
Drum friction diameter295 mm
Drum overall height96 mm
Stud holes5
Stud circle (PCD)120 mm
Centre bore76 mm
Minimum (discard) thickness296.5 mm
Part weight11.2 kg
Hole pattern8/5
OE & OEM cross-reference
Supplier part number
600.1967.20
Fits OE / OEM numbers
2H0 609 617
Vehicle fitment
10 variants
| Make & model | Chassis | Variant | Years | Power |
|---|---|---|---|---|
| VW Amarok | 2HA, 2HB… | 2.0 BiTDI | 2010–2012 | 120 kW |
| VW Amarok | 2HA, 2HB… | 2.0 BiTDI 4motion, 2.0 BiTDI CD Highline 4motion | 2010–2012 | 120 kW |
| VW Amarok | 2HA, 2HB… | 2.0 TDI | 2010–2013 | 90 kW |
| VW Amarok | 2HA, 2HB… | 2.0 TDI 4motion | 2010–2013 | 90 kW |
| VW Amarok | 2HA, 2HB… | 2.0 TSI | 2010–2016 | 118 kW |
| VW Amarok | 2HA, 2HB… | 2.0 BiTDI | 2011–now | 132 kW |
| VW Amarok | 2HA, 2HB… | 2.0 BiTDI 4motion, 2.0 CD Highline Trendline BiTDI 4motion | 2011–now | 132 kW |
| VW Amarok | 2HA, 2HB… | 2.0 TDI, 2.0 TDI CS | 2012–now | 103 kW |
| VW Amarok | 2HA, 2HB… | 3.0 TDI 4motion, 3.0 TDI Highline V6 4motion | 2016–now | 165 kW |
| VW Amarok | 2HA, 2HB… | 3.0 TDI 4motion | 2018–now | 190 kW |
Product overview
Zimmermann 600.1967.20 is a pair of brake drums. Each drum has a 295 mm friction diameter and a 335 mm outside diameter, and stands 96 mm tall. Each drum has 5 stud holes on a 120 mm stud circle (PCD), with a 76 mm centre bore. The drums are coated for corrosion protection. Cross-referenced to VAG OE 2H0 609 617. Confirmed to fit 10 Australian-market variants; the full list is in the fitment table on this page.
