Zimmermann 348mm Brake Disc Set (2 pcs) 150.3441.20
Part No. 150.3441.20
Check this part fits your car
Select your vehicle and we will confirm it against the 15 variants listed for this part.
$486.00
incl. GST
Front axle
348 x 30 mm
Fits 15 vehicle variants
Returned items must be unused and in the original unopened packaging. Return postage is paid by the buyer.
Estimate delivery date and cost
Technical specification
Disc typeInternally vented
Iron gradeHigh-carbon cast iron
Surface finishCorrosion-protective coating
Outside diameter348 mm
Thickness when new30 mm
Height73 mm
Stud holes5
Stud circle (PCD)120 mm
Centre bore120 mm
ApprovalECE R90 approved
Minimum (discard) thickness28.4 mm
Part weight11.2 kg
Hole pattern6/5
OE & OEM cross-reference
Supplier part number
150.3441.20
Fits OE / OEM numbers
3411 6 770 729
3411 6 855 000
Vehicle fitment
15 variants
| Make & model | Chassis | Variant | Years | Power |
|---|---|---|---|---|
| BMW 3 Series | E90 | 330 i, 330 i M Sport | 2004–2011 | 190 kW |
| BMW 3 Series | E90 | 335 i, 335 i M Sport | 2006–2011 | 225 kW |
| BMW 3 Series | E90 | 330 i | 2007–2011 | 200 kW |
| BMW 3 Series | E90 | 330 d | 2008–2011 | 180 kW |
| BMW 3 Series Convertible | E93 | 335 i | 2006–2013 | 225 kW |
| BMW 3 Series Convertible | E93 | 330 i | 2007–2013 | 200 kW |
| BMW 3 Series Convertible | E93 | 330 d | 2009–2013 | 180 kW |
| BMW 3 Series Coupe | E92 | 335 i | 2006–2013 | 225 kW |
| BMW 3 Series Coupe | E92 | 330 i | 2006–2010 | 200 kW |
| BMW 3 Series Coupe | E92 | 330 d | 2009–2013 | 180 kW |
Product overview
Zimmermann 150.3441.20 is a pair of internally vented brake discs (rotors). Each disc is 348 mm in diameter and 30 mm thick when new, with a 73 mm hat height. The minimum (discard) thickness is 28.4 mm. Each disc has 5 stud holes on a 120 mm stud circle (PCD), with a 120 mm centre bore. The discs are coated for corrosion protection and made from high-carbon cast iron. They are ECE R90 approved, the European type-approval standard for replacement brake parts. Cross-referenced to BMW OE 3411 6 770 729 and 1 other OE number. Confirmed to fit 15 Australian-market variants; the full list is in the fitment table on this page.
