Home/ Brakes/ Brake Pads/ Zimmermann Brake Pad Set 239.1417.03

Zimmermann

Zimmermann Brake Pad Set 239.1417.03

Name: Zimmermann Brake Pad Set 239.1417.03
Brand: Zimmermann
SKU: ZIM-00139
Price: 116.00 AUD
Availability: InStock

Part No. 239.1417.03

In stock 19 OE references

Check this part fits your car

Select your vehicle and we will confirm it against the 45 variants listed for this part.

$116.00 incl. GST

Rear axle Lucas-Girling 17 mm Accepts a wear sensor Retaining spring and Fitting bolts Fits 45 vehicle variants

Manufacturer's warranty Processed within 2 business days 30-day change-of-mind returns

Returned items must be unused and in the original unopened packaging. Return postage is paid by the buyer.

Estimate delivery date and cost

Technical specification

Caliper make (factory-fitted)Lucas-Girling

Width105 mm

Height56 mm

Thickness17 mm

Wear sensorAccepts a wear sensor

NotesThe photo shows what you receive, Retaining spring included

Disc typeVented

In the boxFitting bolts included

ApprovalECE R90 approved

OE & OEM cross-reference

Supplier part number

239.1417.03

Fits OE / OEM numbers

1K0 698 451 H 1K0 698 451 1K0 698 451 B 1K0 698 451 D 1K0 698 451 E 1K0 698 451 F 1K0 698 451 H 1K0 698 451 K 3C0 698 451 3C0 698 451 A 3C0 698 451 B 3C0 698 451 C 4F0 698 451 A 4F0 698 451 D 4F0 698 451 E 8E0 698 451 F 8E0 698 451 J 1K0 698 451 H 1K0 698 451 H

Vehicle fitment

45 variants

Make & model	Chassis	Variant	Years	Power
Audi A3	8P1	3.2 V6 quattro	2003–2009	184 kW
Audi A3	8P1	2.0 TFSI	2004–2012	147 kW
Audi A3	8P1	2.0 TFSI quattro	2004–2012	147 kW
Audi A3	8P1	1.8 TFSI	2006–2012	118 kW
Audi A3	8P1	S3 quattro	2007–2012	188 kW
Audi A3	8P1	1.4 TFSI	2007–2012	92 kW
Audi A3 Sportback	8PA	2.0 TFSI	2004–2013	147 kW
Audi A3 Sportback	8PA	2.0 TFSI quattro	2004–2013	147 kW
Audi A3 Sportback	8PA	3.2 V6 quattro	2004–2009	184 kW
Audi A3 Sportback	8PA	1.4 TFSI	2007–2013	92 kW
Audi A3 Sportback	8PA	2.0 quattro, S3 quattro	2008–2013	188 kW
Audi A4 B7	8EC	3.2 FSI	2005–2008	188 kW
Audi A4 B7	8EC	3.2 FSI quattro	2005–2008	188 kW
Audi A4 B7 Convertible	8HE	2.0 TFSI 16V	2006–2009	147 kW
Audi A6 C6	4F2	2.4	2004–2008	130 kW
Audi A6 C6	4F2	3.2 FSI	2004–2009	188 kW
Audi A6 C6	4F2	3.2 FSI quattro	2004–2008	188 kW
Audi A6 C6	4F2	3.0 TFSI quattro	2008–2011	213 kW
Audi TT	8J3	2.0 TFSI	2006–2010	147 kW
Audi TT	8J3	2.0 TTS quattro	2008–2014	200 kW
Audi TT	8J3	1.8 TFSI	2008–2014	118 kW
Audi TT	8J3	2.0 TFSI quattro	2008–2010	147 kW
Audi TT	8J3	2.5 RS quattro	2009–2014	250 kW
Audi TT	8J3	2.0 45 TFSI quattro, 2.0 TFSI quattro	2010–2014	155 kW
Audi TT	8J3	2.0 45 TFSI, 2.0 TFSI	2010–2014	155 kW
Audi TT	8J3	2.5 RS quattro	2011–2014	265 kW
Audi TT Roadster	8J9	2.0 TFSI	2007–2010	147 kW
Audi TT Roadster	8J9	3.2 V6 quattro	2007–2010	184 kW
Audi TT Roadster	8J9	2.0 TTS quattro	2008–2014	200 kW
Audi TT Roadster	8J9	1.8 TFSI	2008–2014	118 kW
Audi TT Roadster	8J9	2.5 RS quattro	2009–2014	250 kW
VW CC B7	358	3.6 FSI 4motion	2011–2016	220 kW
VW Eos	1F7, 1F8	2.0 TFSI	2006–2015	147 kW
VW Eos	1F7, 1F8	2.0 TSI	2009–2015	155 kW
VW Golf V	1K1	2.0 GTI	2004–2009	147 kW
VW Golf V	1K1	3.2 R32 4motion	2005–2008	184 kW
VW Golf VI	5K1	2.0 R 4motion	2009–2013	188 kW
VW Passat B6	3C2	2.0 FSI, 2.0 FSI Confortline	2005–2010	110 kW
VW Passat B6	3C2	2.0 TFSI	2005–2010	147 kW
VW Passat B6	3C2	3.2 FSI 4motion	2005–2010	184 kW
VW Passat B6	3C2	3.6 R36 4motion	2007–2010	220 kW
VW Passat B6	3C2	1.8 TSI	2007–2010	118 kW
VW Passat B6 Estate	3C5	3.2 FSI 4motion, 3.2 FSI Highline 4motion	2005–2010	184 kW
VW Passat B6 Estate	3C5	3.6 R36 4motion	2007–2010	220 kW
VW Scirocco III	137, 138	2.0 R	2009–2017	188 kW
No vehicles match your search.

Product overview

Zimmermann 239.1417.03 is a brake pad set for vehicles fitted with Lucas-Girling calipers. The pads are 105 mm wide, 56 mm tall, and 17 mm thick. The pads are machined to take a wear sensor. In the box: retaining spring and fitting bolts. It is ECE R90 approved, the European type-approval standard for replacement brake parts. Cross-referenced to Skoda OE 1K0 698 451 H and 15 other OE numbers. Confirmed to fit 45 Australian-market variants; the full list is in the fitment table on this page.
