Zimmermann 310mm Brake Disc Set (2 pcs) 100.3309.20

Name: Zimmermann 310mm Brake Disc Set (2 pcs) 100.3309.20
Brand: Zimmermann
SKU: ZIM-00008
Price: 328.00 AUD
Availability: InStock

Part No. 100.3309.20

Low stock 5 OE references

Check this part fits your car

Select your vehicle and we will confirm it against the 181 variants listed for this part.

$328.00 incl. GST

Rear axle 310 x 22 mm Fits 181 vehicle variants

Manufacturer's warranty Processed within 2 business days 30-day change-of-mind returns

Returned items must be unused and in the original unopened packaging. Return postage is paid by the buyer.

Estimate delivery date and cost

Technical specification

Disc typeExternally vented

Iron gradeHigh-carbon cast iron

Surface finishCorrosion-protective coating

Outside diameter310 mm

Thickness when new22 mm

Height49 mm

Stud holes5

Stud circle (PCD)112 mm

Centre bore65 mm

ApprovalECE R90 approved

Minimum (discard) thickness20 mm

Part weight6.8 kg

Hole pattern10/5

OE & OEM cross-reference

Supplier part number

100.3309.20

Fits OE / OEM numbers

5Q0 615 601 S 1K0 615 601 N 5Q0 615 601 E 5QM 615 601 A 3QD 615 601 A

Vehicle fitment

181 variants

Make & model	Chassis	Variant	Years	Power
Audi A3	8P1	2.0 FSI	2003–2008	110 kW
Audi A3	8P1	3.2 V6 quattro	2003–2009	184 kW
Audi A3	8P1	2.0 TFSI	2004–2012	147 kW
Audi A3	8P1	2.0 TFSI quattro	2004–2012	147 kW
Audi A3	8P1	2.0 TDI	2006–2012	125 kW
Audi A3	8P1	1.8 TFSI	2006–2012	118 kW
Audi A3	8P1	S3 quattro	2007–2012	188 kW
Audi A3	8V1, 8VK	1.4 TFSI	2012–2014	90 kW
Audi A3	8V1, 8VK	1.8 TFSI	2012–2016	132 kW
Audi A3	8V1, 8VK	2.0 TDI	2012–2017	110 kW
Audi A3	8V1, 8VK	1.8 TFSI quattro	2012–2016	132 kW
Audi A3	8V1, 8VK	S3 quattro	2013–2014	206 kW
Audi A3	8V1, 8VK	1.4 TFSI	2013–2016	103 kW
Audi A3	8V1, 8VK	1.6 TDI	2013–2017	81 kW
Audi A3	8V1, 8VK	1.4 TFSI	2014–2016	92 kW
Audi A3	8V1, 8VK	1.4 TSI	2014–2017	110 kW
Audi A3	8V1, 8VK	S3 quattro	2014–2016	210 kW
Audi A3	8V1, 8VK	2.0 TFSI	2016–2017	140 kW
Audi A3	8V1, 8VK	S3 quattro	2016–2017	213 kW
Audi A3 Sedan	8VS, 8VM	1.4 TFSI	2013–now	103 kW
Audi A3 Sedan	8VS, 8VM	1.8 TFSI	2013–now	132 kW
Audi A3 Sedan	8VS, 8VM	2.0 TDI	2013–2020	110 kW
Audi A3 Sedan	8VS, 8VM	S3 quattro	2013–now	206 kW
Audi A3 Sedan	8VS, 8VM	1.8 TFSI	2013–2020	125 kW
Audi A3 Sedan	8VS, 8VM	1.8 TFSI quattro	2013–now	132 kW
Audi A3 Sedan	8VS, 8VM	1.4 TFSI Ambiente Attraction, 1.4 TSI	2014–2020	110 kW
Audi A3 Sedan	8VS, 8VM	S3 quattro	2014–now	210 kW
Audi A3 Sedan	8VS, 8VM	2.0 TFSI	2016–2020	140 kW
Audi A3 Sedan	8VS, 8VM	2.0 TFSI quattro	2016–2020	140 kW
Audi A3 Sedan	8VS, 8VM	S3 quattro	2016–2020	213 kW
Audi A3 Sedan	8VS, 8VM	RS3 quattro	2017–2020	294 kW
Audi A3 Convertible	8V7, 8VE	1.4 TFSI	2013–now	103 kW
Audi A3 Convertible	8V7, 8VE	1.8 40 TFSI, 1.8 TFSI	2013–2016	132 kW
Audi A3 Convertible	8V7, 8VE	2.0 TDI	2013–2020	110 kW
Audi A3 Convertible	8V7, 8VE	1.8 TFSI quattro	2014–now	132 kW
Audi A3 Convertible	8V7, 8VE	S3 quattro	2014–now	210 kW
Audi A3 Convertible	8V7, 8VE	1.4 TSI	2014–2020	110 kW
Audi A3 Convertible	8V7, 8VE	2.0 40 TFSI, 2.0 TFSI	2016–2020	140 kW
Audi A3 Convertible	8V7, 8VE	2.0 TFSI quattro	2016–2020	140 kW
Audi A3 Sedan	8YS	35 TFSI Mild Hybrid	2020–now	110 kW
Audi A3 Sportback	8PA	2.0 FSI	2004–2008	110 kW
Audi A3 Sportback	8PA	2.0 TFSI	2004–2013	147 kW
Audi A3 Sportback	8PA	2.0 TFSI quattro	2004–2013	147 kW
Audi A3 Sportback	8PA	3.2 V6 quattro	2004–2009	184 kW
Audi A3 Sportback	8PA	2.0 TDI	2006–2013	125 kW
Audi A3 Sportback	8PA	1.8 TFSI	2006–2013	118 kW
Audi A3 Sportback	8PA	2.0 quattro, S3 quattro	2008–2013	188 kW
Audi A3 Sportback	8VA, 8VF	1.4 TFSI, 1.4 TFSI Attraction	2012–2020	90 kW
Audi A3 Sportback	8VA, 8VF	1.8 40 TFSI, 1.8 TFSI	2012–now	132 kW
Audi A3 Sportback	8VA, 8VF	2.0 TDI	2012–2020	110 kW
Audi A3 Sportback	8VA, 8VF	1.6 TDI	2012–now	77 kW
Audi A3 Sportback	8VA, 8VF	1.4 TFSI	2013–now	103 kW
Audi A3 Sportback	8VA, 8VF	1.8 TFSI quattro	2013–now	132 kW
Audi A3 Sportback	8VA, 8VF	2.0 quattro, S3 quattro	2013–now	206 kW
Audi A3 Sportback	8VA, 8VF	1.6 TDI	2013–2020	81 kW
Audi A3 Sportback	8VA, 8VF	1.4 TFSI	2014–2016	92 kW
Audi A3 Sportback	8VA, 8VF	1.4 TSI	2014–2020	110 kW
Audi A3 Sportback	8VA, 8VF	S3 quattro	2014–2016	210 kW
Audi A3 Sportback	8VA, 8VF	RS3 quattro	2015–now	270 kW
Audi A3 Sportback	8VA, 8VF	2.0 TFSI	2016–2020	140 kW
Audi A3 Sportback	8VA, 8VF	2.0 TFSI quattro	2016–2020	140 kW
Audi A3 Sportback	8VA, 8VF	1.0 TFSI	2016–2020	85 kW
Audi A3 Sportback	8VA, 8VF	S3 quattro	2016–2020	213 kW
Audi A3 Sportback	8VA, 8VF	1.6 TDI	2017–2020	85 kW
Audi A3 Sportback	8VA, 8VF	RS3 quattro	2017–2020	294 kW
Audi A3 Sportback	8YA	35 TFSI Mild Hybrid	2020–now	110 kW
Audi Q2	GAB, GAG	1.4 TFSI	2016–now	110 kW
Audi Q2	GAB, GAG	2.0 TDI quattro	2016–now	110 kW
Audi Q2	GAB, GAG	2.0 TFSI quattro	2017–now	140 kW
Audi Q3	F3B	35 TFSI	2018–now	110 kW
Audi Q3	F3B	2.5 RS quattro	2019–now	294 kW
Audi Q3 Sportback	F3N	2.5 RS quattro	2019–now	294 kW
Audi TT	FV3, FVP	2.0 TFSI quattro	2014–now	169 kW
Audi TT	FV3, FVP	2.0 TFSI, 2.0 TFSI Ambition Attraction	2014–now	169 kW
Audi TT	FV3, FVP	2.0 TTS quattro	2015–now	210 kW
Audi TT	FV3, FVP	2.5 RS quattro	2016–now	294 kW
Audi TT Roadster	FV9, FVR	2.0 TFSI	2014–now	169 kW
Audi TT Roadster	FV9, FVR	2.0 TFSI quattro	2014–now	169 kW
Audi TT Roadster	FV9, FVR	2.0 TTS quattro	2015–now	210 kW
Audi TT Roadster	FV9, FVR	2.5 RS quattro	2016–now	294 kW
VW Arteon	3H7, 3H8	2.0 TSI 4motion	2017–now	206 kW
VW Arteon	3H7, 3H8	2.0 TSI	2017–now	140 kW
VW Arteon Shooting Brake	3H9	2.0 TSI 4motion	2020–now	206 kW
VW Arteon Shooting Brake	3H9	2.0 TSi	2020–now	140 kW
VW CC B6	357	3.6 FSI 4motion	2008–2011	220 kW
VW CC B6	357	2.0 TDI	2008–2012	125 kW
VW CC B7	358	2.0 TDI	2011–2016	125 kW
VW CC B7	358	3.6 FSI 4motion	2011–2016	220 kW
VW CC B7	358	2.0 TDI	2012–2016	130 kW
VW Eos	1F7, 1F8	2.0 TFSI	2006–2015	147 kW
VW Eos	1F7, 1F8	2.0 TDI	2006–2008	103 kW
VW Eos	1F7, 1F8	3.2 V6, 3.2 VR6	2006–2009	184 kW
VW Eos	1F7, 1F8	2.0 TDI 16V	2008–2015	103 kW
VW Eos	1F7, 1F8	2.0 TSI	2009–2015	155 kW
VW Golf Alltrack VII Estate	BA5, BV5	1.8 TSI 4motion	2014–2020	132 kW
VW Golf V	1K1	1.6 FSI	2003–2008	85 kW
VW Golf V	1K1	1.9 TDI	2003–2008	77 kW
VW Golf V	1K1	2.0 TDI 16V	2003–2008	103 kW
VW Golf V	1K1	1.6	2004–2008	75 kW
VW Golf V	1K1	2.0 FSI	2004–2008	110 kW
VW Golf V	1K1	2.0 GTI	2004–2009	147 kW
VW Golf V	1K1	2.0 TDI	2004–2008	103 kW
VW Golf V	1K1	1.4 GT Sport TSI, 1.4 TSI	2005–2008	125 kW
VW Golf V	1K1	2.0 GT Sport TDI, 2.0 TDI	2005–2008	125 kW
VW Golf V	1K1	3.2 R32 4motion	2005–2008	184 kW
VW Golf V	1K1	2.0 GTI	2006–2008	169 kW
VW Golf V	1K1	1.4 TSI	2007–2008	90 kW
VW Golf VI	5K1	1.4 TSI	2008–2012	90 kW
VW Golf VI	5K1	1.4 TSI	2008–2012	118 kW
VW Golf VI	5K1	2.0 TDI	2008–2013	103 kW
VW Golf VI	5K1	1.2 TSI	2008–2012	77 kW
VW Golf VI	5K1	1.6 TDI	2009–2012	77 kW
VW Golf VI	5K1	2.0 GTD, 2.0 TDI	2009–2012	125 kW
VW Golf VI	5K1	2.0 GTi	2009–2012	155 kW
VW Golf VI	5K1	2.0 R 4motion	2009–2013	188 kW
VW Golf VI	5K1	2.0 GTi	2011–2012	173 kW
VW Golf VII	5G1, BQ1, BE1, BE2	1.4 TSI, 1.4 TSI, Highline	2012–2017	103 kW
VW Golf VII	5G1, BQ1, BE1, BE2	2.0 TDI	2012–2020	110 kW
VW Golf VII	5G1, BQ1, BE1, BE2	1.4 TSI	2012–2017	90 kW
VW Golf VII	5G1, BQ1, BE1, BE2	2.0 GTI	2013–2020	169 kW
VW Golf VII	5G1, BQ1, BE1, BE2	2.0 GTI, 2.0 TSI GTI	2013–2020	162 kW
VW Golf VII	5G1, BQ1, BE1, BE2	2.0 R 4motion, 2.0 TSI R 4motion	2013–2017	206 kW
VW Golf VII	5G1, BQ1, BE1, BE2	1.4 TSI	2014–2020	92 kW
VW Golf VII	5G1, BQ1, BE1, BE2	1.4 TSI	2014–2021	110 kW
VW Golf VII	5G1, BQ1, BE1, BE2	2.0 GTI Clubsport	2016–2017	195 kW
VW Golf VII	5G1, BQ1, BE1, BE2	2.0 R 4motion	2016–2020	213 kW
VW Golf VII	5G1, BQ1, BE1, BE2	2.0 GTI	2017–2020	180 kW
VW Golf VII Estate	BA5, BV5	1.4 TSI	2014–2020	92 kW
VW Golf VII Estate	BA5, BV5	2.0 R 4motion	2015–2017	206 kW
VW Golf VII Estate	BA5, BV5	2.0 R 4motion	2016–2020	213 kW
VW Passat B7 Estate	365	1.8 TSI	2010–2014	118 kW
VW Passat B7 Estate	365	2.0 TDI	2010–2014	125 kW
VW Passat B7 Estate	365	3.6 FSI 4motion	2011–2014	220 kW
VW Passat B7 Estate	365	2.0 TDI	2012–2014	130 kW
VW Passat B6	3C2	2.0 FSI, 2.0 FSI Confortline	2005–2010	110 kW
VW Passat B6	3C2	2.0 TDI 16V	2005–2010	103 kW
VW Passat B6	3C2	2.0 TFSI	2005–2010	147 kW
VW Passat B6	3C2	2.0 TDI	2005–2010	125 kW
VW Passat B6	3C2	3.2 FSI 4motion	2005–2010	184 kW
VW Passat B6	3C2	3.6 R36 4motion	2007–2010	220 kW
VW Passat B6	3C2	1.8 TSI	2007–2010	118 kW
VW Passat B6	3C2	2.0 FSI	2007–2010	125 kW
VW Passat Alltrack B7	365	2.0 TDI 4motion	2012–2014	125 kW
VW Passat Alltrack B7	365	2.0 TDI 4motion	2013–2014	130 kW
VW Passat Alltrack B8 Estate	3G5, CB5	2.0 TDI 4motion	2015–now	140 kW
VW Passat Alltrack B8 Estate	3G5, CB5	2.0 380 TSI 4motion, 2.0 TSI 4motion	2015–now	162 kW
VW Passat B6 Estate	3C5	1.9 TDI	2005–2010	77 kW
VW Passat B6 Estate	3C5	2.0 TDI	2005–2009	103 kW
VW Passat B6 Estate	3C5	2.0 TDI	2005–2010	125 kW
VW Passat B6 Estate	3C5	2.0 TDI 16V	2005–2010	103 kW
VW Passat B6 Estate	3C5	2.0 TDI 16V 4motion	2005–2010	103 kW
VW Passat B6 Estate	3C5	2.0 TFSI	2005–2010	147 kW
VW Passat B6 Estate	3C5	3.2 FSI 4motion, 3.2 FSI Highline 4motion	2005–2010	184 kW
VW Passat B6 Estate	3C5	3.6 R36 4motion	2007–2010	220 kW
VW Passat B6 Estate	3C5	1.8 TSI	2007–2011	118 kW
VW Passat B7	362	1.8 TSI	2010–2014	118 kW
VW Passat B7	362	2.0 TDI	2010–2014	125 kW
VW Passat B7	362	3.6 FSI 4motion	2011–2014	220 kW
VW Passat B7	362	2.0 TDI	2012–2014	130 kW
VW Passat B8	3G2, CB2	2.0 TDI	2014–now	140 kW
VW Passat B8	3G2, CB2	1.8 TSI	2015–now	132 kW
VW Passat B8	3G2, CB2	2.0 TSI, 2.0 TSI Comfortline Highline	2015–now	162 kW
VW Passat B8	3G2, CB2	2.0 TSI 4motion	2015–now	206 kW
VW Passat B8	3G2, CB2	2.0 TSI	2018–now	140 kW
VW Passat B8 Estate	3G5, CB5	2.0 380 TSI, 2.0 TSI	2014–now	162 kW
VW Passat B8 Estate	3G5, CB5	2.0 TDI	2014–now	140 kW
VW Passat B8 Estate	3G5, CB5	2.0 TDI 4motion	2014–now	140 kW
VW Passat B8 Estate	3G5, CB5	1.8 TSI	2015–now	132 kW
VW Passat B8 Estate	3G5, CB5	2.0 TSI 4motion	2015–now	206 kW
VW Passat B8 Estate	3G5, CB5	2.0 TSI	2018–now	140 kW
VW Scirocco III	137, 138	2.0 R	2009–2017	188 kW
VW Tiguan	AD1, AX1	2.0 330 TSI 4motion, 2.0 TSI 4motion	2016–now	132 kW
VW Tiguan	AD1, AX1	2.0 TDI 4motion	2016–2020	110 kW
VW Tiguan	AD1, AX1	2.0 TDI 4motion	2016–2020	140 kW
VW Tiguan	AD1, AX1	1.4 280 TSI, 1.4 TSI	2016–now	110 kW
VW Tiguan	AD1, AX1	2.0 380 TSI 4motion, 2.0 TSI 4motion	2016–now	162 kW
VW Tiguan	BW2, BJ2	2.0 TSI 4motion	2017–now	132 kW
VW Tiguan	BW2, BJ2	1.4 TSI	2017–now	110 kW
VW Tiguan	BW2, BJ2	2.0 TDI 4motion	2017–now	110 kW
VW Tiguan	BW2, BJ2	2.0 TDI 4motion	2017–2021	140 kW
VW Tiguan	BW2, BJ2	2.0 TSI 4motion	2017–now	162 kW
No vehicles match your search.

Product overview

Zimmermann 100.3309.20 is a pair of externally vented brake discs (rotors). Each disc is 310 mm in diameter and 22 mm thick when new, with a 49 mm hat height. The minimum (discard) thickness is 20 mm. Each disc has 5 stud holes on a 112 mm stud circle (PCD), with a 65 mm centre bore. The discs are coated for corrosion protection and made from high-carbon cast iron. They are ECE R90 approved, the European type-approval standard for replacement brake parts. Cross-referenced to VAG OE 5Q0 615 601 S and 4 other OE numbers. Confirmed to fit 181 Australian-market variants; the full list is in the fitment table on this page.
